OBP V3 Alloy Splitable Dry Sump Tank

OBP V3 Alloy Splitable Dry Sump Tank

The OBP V3 Alloy Dry Sump Tank represents the latest advancement in high-performance oil management, specifically designed for motorsport and serious performance applications. Created and handcrafted in our UK facility, the V3 model builds on the successful performance of its predecessors with enhanced oil cooling, superior deaeration, and a new split-body design for easier cleaning and maintenance.

Constructed from 2mm aluminium and pressure tested for durability, this dry sump tank features a unique cylindrical internal baffle system and a side-mounted inlet, which promotes swirling oil motion. This design aids in air/oil separation and ensures consistent oil pressure during aggressive driving conditions.

What Is a Dry Sump Tank Used For?

In a dry sump lubrication system, oil is stored externally in a dedicated tank rather than in the engine’s sump. This configuration is ideal for racing and high-performance vehicles as it improves oil control, reduces the risk of oil starvation, and allows for lower engine placement. The OBP V3 Dry Sump Tank is designed to optimise internal oil movement and air separation, ensuring reliable lubrication for your engine even under extreme conditions.

New Features: Split Design with Viton Gasket for Easy Servicing

The V3 Dry Sump Tank features a split-body design that allows for easy disassembly, providing full internal access for cleaning and maintenance. It is sealed with a high-quality Viton gasket, which offers excellent resistance to oil, fuel, and heat, ensuring a long-lasting and leak-proof seal.

Key Features of the OBP V3 Alloy Splitable Dry Sump Tank include:

Race-Ready Construction ** – This dry sump tank is expertly engineered for the rigorous demands of competitive motorsport, ensuring maximum durability and performance even under extreme conditions.

Improved Cooling & Deaeration – The innovative cylindrical baffles and strategically positioned side inlets greatly enhance the internal oil circulation, optimising cooling and reducing the chances of aeration for consistent oil pressure.

User-Friendly Split Design with Viton Gasket – The tank features a split design that makes it exceptionally easy to clean and maintain, while the high-quality Viton gasket ensures a reliable seal to prevent leaks.

Side M22x1.5 Female Inlet – This inlet design enables efficient circular oil flow within the tank, promoting effective oil management during high-performance driving.

M22x1.5 Female Centre Outlet – Located within the calm zone of the baffle, this outlet draws clean oil to the pump, minimising the risk of returning aerated oil to the engine.

Twin AN8 Female Breather Ports – These versatile ports accommodate a variety of breather configurations, allowing for tailored setups to suit your specific racing needs.

AN6 Drain Port (Plug Included) – Facilitates rapid and mess-free oil draining, simplifying the maintenance process and ensuring that oil changes are quick and efficient.

Low-Profile 50mm Screw Cap – The compact design of the filler cap allows for easy access, making it convenient to top off oil or conduct routine checks without hassle.

Base Mounted Design – The tank is securely mounted at its base, providing a low centre of gravity that enhances stability during aggressive driving.

Handmade in the UK – Each tank is meticulously crafted from 2mm aluminium and undergoes rigorous pressure testing to guarantee superior quality before it reaches your hands.

Available Capacities & Specifications:

1.5 Gallon V3 Dry Sump Tank:
– Part Number: OBPV3DS02
– Dimensions: Height: 275mm | Diameter: 190mm
– Inlet: M22x1.5 Female (side-mounted)
– Outlet: M22x1.5 Female (center-mounted inside baffle), designed for optimal oil draw
– Breather Ports: 2x AN8 Female, perfect for diverse breather setups
– Drain: AN6 with plug, ensuring a clean and quick draining process
– Filler Cap: 50mm Low-Profile Screw Cap for easy accessibility
– Split Design: Yes, equipped with a durable Viton gasket
– Mounting: Base mounted for added stability
– Material: 2mm aluminium, known for strength and lightweight properties

2 Gallon V3 Dry Sump Tank:
– Part Number: OBPV3DS03
– Dimensions: Height: 360mm | Diameter: 190mm
– Inlet: M22x1.5 Female (side-mounted)
– Outlet: M22x1.5 Female (center-mounted inside baffle), maximising clean oil delivery
– Breather Ports: 2x AN8 Female, adaptable for custom breather configurations
– Drain: AN6 with plug, designed for efficient oil removal
– Filler Cap: 50mm Low-Profile Screw Cap for straightforward access
– Split Design: Yes, featuring a high-quality Viton gasket for a reliable seal
– Mounting: Base mounted to ensure a secure fit during operation
– Material: 2mm aluminium, combining durability with lightweight design

Whether you are embarking on a complete race build or seeking to elevate your dry sump system for enhanced oil management, the OBP V3 Dry Sump Tank is engineered to deliver unparalleled functionality, exceptional reliability, and performance that meets the highest motorsport standards.
